Operating Environment Temperature:－20℃~＋40℃，the temperature of materials below 50℃
Usage: the link of keeping continuous between the machines, Increasing productivity and reducing labor intensity.
Features: Compact structure, easy maintenance, large conveying capacity, long conveying distance
Applications: Aggregate Field, Concrete Mixing Plant, Dry Mortar Plant Desulfurization, Quartz Sand etc.
Working Principle
Belt conveyor is mainly composed of frame, conveyor belt, roller, roller, tensioning device, transmission device, etc.The drum that the belt conveyor belt rotates is the driving drum, and the drum that is only used to change the direction of the conveyor belt movement is called the reversing drum. The driving drum is driven by the motor through the reducer, and the conveyor belt is dragged by the friction between the driving drum and the conveyor belt. The driving roller is generally installed at the discharge end to increase traction and facilitate dragging. The material is fed through the feed end and falls onto the rotating conveyor belt, which is driven by the friction of the conveyor belt to the unloading end and discharged.
Technical Data
Belt Width（mm） | Belt Length（m）/Power（kw） | Belt Speed（m/s） | Capacity（t/h） | ||
500 | ≤10/18.5 | 12-20/4-5.5 | 20-30/5.5-7.5 | 1.3-1.6 | 45-90 |
650 | ≤10/18.6 | 12-20/5.5 | 20-30/7.5-11 | 1.3-1.6 | 70-120 |
800 | ≤10/18.7 | 10-15/5.5 | 15-25/7.5-15 | 1.3-1.6 | 120-180 |
1000 | ≤10/18.8 | 10-20/7.5-11 | 20-25/11-22 | 1.3-2.0 | 160-250 |
1200 | ≤10/18.9 | 10-20/11 | 20-25/15-30 | 1.3-2.0 | 200-400 |
1400 | ≤10/18.5 | 10-18/22 | 18-25/30 | 1.3-2.0 | 660-1200 |
1600 | ≤10/15 | 10-20/22-30 | 20-50/30-75 | 1.25-2.0 | 600-1080 |
Notes: Any change of technical data shall not be advised additionally.
