Sand Washing Machine Product Introduction

XSD high efficiency sand washing machine is used with the sand making machine, which can wash away fine stone powder and impurities in the mixed sand and improve the quality of the sand. It has the features of high cleaning degree, reasonable structure, large processing capacity, small power consumption and less sand loss during cleaning; The drive part is isolated from water and sand, and the failure rate of the machine is much lower than that of the ordinary sand washing machine, which is the best choice for upgrading the domestic sand washing industry.

Capacity: 20~160t/h

 Sand Washing Machine Working Principle

The power device decelerated by the triangle belt, reducer and gear drives the impeller to rotate slowly, and sands below 10mm enter the washing tank for cleaning. The rotating impeller takes away the clean sands through the screen hole, then are poured into the discharge tank.

 Sand Washing Machine Advantages And Features

1. Simple structure. Impeller transmission bearing isolated from water and sands, so that it protects the bearing from dipping into the water, sand and other pollutants.

2. This machine is automatic and has lower failure rate,the sieve mesh is only wearing part.

3. Use of fully enclosed oil bath transmission device, adjustable overflow weir plate, so that the series of products efficient, durable, cleaning, dehydration effect is good.

Sand Washing Machine Technical Data
